Range 9m
Swivel ring and fine hydraulics make the arm easy to
operate with gentle movements.
The arm has 3 joints at 180 ° which makes the possibilities
with tools many.
- Range 9m
- Flexible.
- Unlimited with working positions
- Can be turned right and left side.
- Attach for large brush Ø1.2m, L = 1.9m
- 2 "hose for water laid out on arm, with swivels in joints.
- Swivel rings for fine movements.
- Weight: 1100 kg.
- Operated with Danfoss Joystick.
- Plus 1 control CAN.
- Possible to output signal for control of external equipment.
- Hydraulics: min. 30l / min, 170 bar. (80l / min if you are going to use a large brush.)
- Electrical connection: 12-24VDC.
- 1/2 ”hydraulics for tools such as brush.
- 2x 1/4 ”hydraulics for special tools with extra functions.
